You can read the shock absorber(s) type like this:

Example: MA456-310TR-78-85

• MA456=Type

• 310=Length in mm

• 78-85=Year of construction

• T=Threaded pre-load=spring pre-load with a screw ring

• R=Rebound=black knob at the bottom=adjustment on the rebound, outgoing damping. When adjusting, the rebound damping is also taken into account.

• L=Length=not many shock absorbers are supplied with length adjustment. If the L is in the article number, then it is.

• C=Compression=Compression adjustment on the reservoir

• W=W stands for double compression adjustment on the reservoir, Hi and Low speed compression is adjustable.

• M=Mono shock

The information in the product title refers to the shock absorber(s) you get.

[Download/Check documentation]

[Download/Check documentation]

Information per model

456 Range Monoshock Topline

Self-adjusting Mono gas dampers - 50mm radial billet milled piston - 16mm hardened shaft with low friction – Long-life seal - Pre-load adjustment with open end spanner - Rebound adjustment 60 clicks - Adjustable length (if technically possible) - Damping and spring are model specific
