    Productinformatie
    Artikelcode: 19-0329
    EAN-code: 7440824212297

    HIGHSIDER LED main headlight FRAME-R2 TYPE 5, E-approved
    - Mounting WITHOUT housing

    Every centimetre counts to place the headlight as narrowly as possible between the two standpipes in the fork. REDUCED TO THE MAX was the premise for the development of the innovative headlamp mount FRAME. With the puristic aluminium ring it is possible for the first time to mount different LED headlight inserts free-standing on the motorcycle. The deliberate omission of a headlamp housing enables an unbeatably narrow installation position and also provides better cooling of the LED unit.

    Seeing better usually also means being seen better at the same time, not unimportant when the summer tends towards autumn and in times when cars are increasingly equipped with bright daytime running lights. Whether you want to replace it for better visibility at night, better recognition during the day, or to give your motorcycle a more beautiful look, if you are looking for a stylish and innovative power headlight, the FRAME-R2 LED headlight is an excellent choice.

    For variable mounting of the headlamp two different mounting systems are available.
    - Side Mount, the conventional screw connection at the side of the lamp holder
    - Bottom Mount, attachment at the bottom for screw connection to the fork bridge

    The Side-Mount holders can be mounted in three positions, thus compensating for 32mm in installation depth and 46mm in width.

    features:
    - Round 5 3/4 inch headlight with CNC mounting ring and mounting kit
    - Mounting WITHOUT a headlight housing
    - Improves cooling
    - Many installation possibilities
    - Flat mounting
    - Modern optics, stylishly innovative
    - Chrome-plated reflector with black bezel and clear glass
    - Long-distance Dipped beam (upper half lights up) and parking light is produced by extra LEDs at the top and at the bottom
    - E-tested, nothing needs to be entered

    Give your bike your unmistakable style! The unusual design and the perfect technology of the HIGHSIDER headlight series makes your bike a highlight in any case!

    Dimensions:
    A Diameter = 165 mm
    GA Diameter = 135 mm
    I Diameter = 145 mm
    T = 60 mm
    R = 27 mm
    Variant side mounting: M8

    connections, power consumption (3 pin connector):
    Red cable = low beam (+), at 12V, 25W (1121,2 lm)
    White cable = high beam (+),at 12V, 21W (1510,7 lm)
    Brown cable = parking light (+), at 12V 0,5 Watt
    Black cable = ground (-)

    1 piece

    Note:
    Asymmetrical use, approved for right-hand traffic only.
